    RCA RLDED4016a-b

    So I got this TV with not turning on symptom.
    Using my backlight tester I confirmed that LED backlight is fine. Ordered a replacement main board TP.MS3393.PB851. With this replacement board TV turned on but original remote control will not work on a TV and side buttons are mixed up(for example if I press "Source" TV will increase volume).
    So I swapped Eeproms and confirmed that it is a problem on my original main board, meaning with my original main board and an Eeprom from replacement board I got TV to turn on with not working remote and mixed up side buttons and the replacement main board with original Eeprom won't turn TV on.
    So I used my CH341A to read the original Eeprom and it reads and writes back in it no problem. Now I have no idea how to fix that Eeprom dump file.
    What puzzles me is the fact that model numbers of the main boards are the same.
    How do I find a proper Eeprom dump for my models of TV and main board?
    Or can someone please help me fix the Eeprom dump?
    Thanks!
    Attached Files
    Tags: None
    • lotas
      Badcaps Legend
      • Jan 2016
      • 4555
      • Russia
      #2
      Re: RCA RLDED4016a-b

      Post the second working dump, I'll try to assemble one from the two.
      Last edited by lotas; 11-09-2023, 01:11 PM.

        Comment

        • Chuper
          Member
          • Sep 2017
          • 36
          • Canada
          #3
          Re: RCA RLDED4016a-b

          Here it is
          Attached Files

            Comment

            • lotas
              Badcaps Legend
              • Jan 2016
              • 4555
              • Russia
              #4
              Re: RCA RLDED4016a-b

              Try.
              Attached Files

                Comment

                • Chuper
                  Member
                  • Sep 2017
                  • 36
                  • Canada
                  #5
                  Re: RCA RLDED4016a-b

                  Both Eeproms now work on both main boards turning TV on and side buttons having correct functions.
                  Thank you, lotas!
                  Remote still won't work though
