    The differential amplifier.

    This is the best video I could find about the most importance of Differential Amplifier. Let me ask you What is current mirror?

    #193: Back to Basics: the differential amplifier, aka long-tailed pair, diff-pair
    https://www.youtube.com/watch?v=mejPNuPAHBY
    Attached Files
    Last edited by capwizard; 02-17-2017, 07:27 AM.
    Tags: None
    • petehall347
      Badcaps Legend
      • Jan 2015
      • 4425
      • United Kingdom
      #2
      Re: The differential amplifier.

      look up ocl-techguide.pdf ...

        Comment

        • jiroy
          Badcaps Legend
          • Jun 2016
          • 2416
          • Lebanon
          #3
          Re: The differential amplifier.

          Notation rarely used this current mirror , who said that and from where did you get it capdude ?..
          I think the right notation is Amplification distortion limiter via Input vs Output maximum capability , related to Linear or non linear Amplification design ..
