    Dual USB port desoldering fail

    Well, I desoldered a broken dual USB port from a laptop motherboard (HP Compaq nx6325) using only my soldering iron. Unfortunately, I managed to mess up the right-side pad on the top side of the motherboard (see picture). Will USB work without this or will some additional wiring be needed?

    Thanks
    Attached Files
    Tags: None
    • dellxps15
      Badcaps Legend
      • Feb 2014
      • 1585
      • italy
      #2
      Re: Dual USB port desoldering fail

      it is the gnd. should work with no problem

        Comment

        • Half-Saint
          Badcaps Veteran
          • Jan 2010
          • 213
          • Slovenia
          #3
          Re: Dual USB port desoldering fail

          Thanks. I thought it would but wasn't sure. Now I need to find a suitable replacement. The pins are quite close together...

            Comment

            • dellxps15
              Badcaps Legend
              • Feb 2014
              • 1585
              • italy
              #4
              Re: Dual USB port desoldering fail

              http://www.ebay.it/itm/Dual-USB-Jack...item5d295a2792

              that should be fine.
