    Dell U2415 service manual

    Hi,
    I have a Dell U2415 monitor with faulty power supply.
    After diagnosing, I have found the switching IC is faulty.

    I have found the IC model is LD7750(this is again an assumption since the model's name is not clear after the burnout)

    However, I cannot find the other surrounding components like SMD resistors and diodes (The numbers are missing)

    if anyone can provide an advice of if have a datasheet of the board or service manual of this model that will be appreciated.

    Thanks
    Nayantha
