Pls share Asus P452SJ Boardview or Schematic file
-
Hi Guys,
I need a motherboard schematic for file for a AORUS 15P XC please. The EXACT motherboard is ga-rx5lxc rev2.0. It currently has a black screen issue and doesn't display to external display but boots into windows and can also display externally when running ubuntu. If anyone has a motherboard schematic file and boardview for this laptop it would be greatly appreciated. Thanks in advance!05-01-2025, 01:45 PM -
Hello,
i'm looking for a schematic/boardview for an ASUS E3-PRO V5 (NOT E3 PRO GAMING, has a different layout).
I'm trying to find out where i can find SKTOCC# other than from the socket in order to ground it for a Coffee Lake mod. It must be somewhere near/around the SIO but I haven't found a datasheet for the NCT5539D this board has.
I've also found the schematic for the similarly named E3 PRO GAMING V5 but it has a different SIO so it's not of much help. And I don't trust myself to hold still a multimeter probe on top of a LGA socket pin to find where it comes out the...01-18-2025, 09:17 AM -
Hello!
I am looking for a schematic (if that's not out there, a boardview would suffice) for the ASUS PRIME H610I-PLUS D4, model 60MB1B20-MB0A01, rev 1.01. Are either of these available anywhere?07-25-2025, 05:11 AM -
I need a schematic or boardview for an ASUS Chromebook CB5500FE laptop. I want to program the Nuvoton NPCX797FC0BX microcontroller, and I don't know how the SWDIO, SWCLK, and nRESET signals are connected.07-20-2025, 04:22 PM -
Hello, I have an issue with the motherboard. Specifically, it doesn't power on, more precisely, the POST initialization doesn't occur.
Let me start from the beginning, the motherboard suddenly stopped working one day. There are no beep signals from the speaker, and the debug LEDs are not lighting up. After inspecting it under a microscope and using thermal imaging, I didn't find anything that could be damaged.
After that, I began voltage measurements, in which I noticed the absence of VDDQ, VDDP, VTT, and VPP lines. Later, I checked if there is an EN state on these lines,...
